UGREEN CM633 5-Port GigaBit Ethernet Switch (Black)

Name: UGREEN CM633 5-Port GigaBit Ethernet Switch (Black)
Brand: Ugreen
SKU: UGR5636
Price: 21.65 EUR
Availability: InStock

Reviews (0)

SKU: UGR5636

EAN: 6941876246885

€21.65

Tax included

Description

UGREEN CM633 – reliable connectivity at gigabit speed

The UGREEN CM633 network switch is the ideal solution for home and office networks, providing stable and fast connections without delays. With 5 gigabit RJ45 Ethernet ports supporting auto-negotiation speeds of 10/100/1000 Mbps, you can connect multiple devices such as computers, Smart TVs, gaming consoles, or network printers. Store-and-Forward technology and full non-blocking bandwidth guarantee maximum transmission performance, without packet loss and speed limitations.

High performance and stability

The UGREEN CM633 is a switch that adapts to your needs. Each of the five ports automatically detects the connection speed and operates at the maximum possible bandwidth. With support for full and half-duplex mode, the device can simultaneously send and receive data, increasing network efficiency. The Auto MDI/MDIX feature eliminates the need for special crossover cables – just connect a standard cable and the switch will automatically adjust the configuration. With a bandwidth of 10 Gbps, even during intensive use, such as video streaming or transferring large files, the network operates smoothly, without delays or drops in speed.

Solid construction and intelligent cooling

The UGREEN CM633 features a metal housing with a ventilation system that effectively dissipates heat and increases the device's durability. Silent operation makes this switch perfect for both office and home use.

Easy installation and energy savings

Thanks to the Plug & Play feature, the device does not require complicated configuration – just connect the cables, and the switch will automatically recognize the connected devices and adjust the transmission parameters. Additionally, the energy-saving technology dynamically adjusts power consumption, reducing energy usage without affecting network performance.

Manufacturer	UGREEN
Model	CM633
Manufacturer code	15641EU
PoE (Power over Ethernet) support	No
Network standards	IEEE 802.3/u/x/ab
Number of ports	5 × RJ45
Speeds	10/100/1000 Mbps (auto-negotiation)
Supported features	Auto MDI/MDIX; Support for full and half-duplex transmission modes; Dynamic learning and aging of MAC address entries; Full non-blocking bandwidth
LED indicators	1 × power indicator; 5 × connection and activity indicator (Link/Act)
Transmission medium	10Base-T: Cat 3 cable or newer (max. 100 m); 100Base-TX: Cat 5 cable or newer (max. 100 m); 1000Base-T: Cat 5 cable or newer (max. 100 m)
Bandwidth	10 Gbps
Transmission method	Store-and-Forward
Packet forwarding rate	10 Mbps: 14,880 pps/port; 100 Mbps: 148,800 pps/port; 1000 Mbps: 1,488,000 pps/port
MAC address table	2K entries
Jumbo frame buffering	9K
Input	AC 100-240V 50Hz/60Hz
Output	DC 5.0V = 1.0A Max
Operating temperature	0°C – 40°C
Operating humidity	10% – 90% RH, non-condensing
Storage temperature	-40°C – 70°C
Storage humidity	5% – 90% RH, non-condensing
